KRON XN16

Operational weight

1,4 T

Max. digging depth

2167 mm

Bucket capacity

0,045 cube

Описание

Main technical parameters

Model

XN16

Operating weight

1,4 T

Bucket capacity

0,045 cube

Bucket width

380мм

Rated power

10,2 kW

BASIC DIMENSIONS

Dimensions (LxWxH)

2330x1130x2575 mm

Wheelbase

1130mm

The total length of the path on land

1450mm

Platform ground clearance

420mm

Chassis Width

1110mm

WORKING RANGE

Maximum. Digging depth

2167 mm

Maximum. Vertical dig depth

1740mm

Maximum. Digging Height

3258mm

Maximum. Drop Height

2293mm

Maximum. Digging radius on the ground

3513mm

Min. Rotation radius

1440 mm
